KFL 30LED, EPI-Fluorescent Microscope is used for fluorescence microscopy and transmitted field observation. It is equipped with chromatic aberration infinity plan achromatic fluorescent objectives & wide field eyepieces, has clear picture & wide view field. The transmitted and Epi-fluorescent illumination light source are high power & brightness LED, but power consumption is lower and use life longer, with very good radiating heat effect. Safely and comfortably using the instrument, the cost of use and maintenance are lower. It is the ideal instrument in biology, cytology, oncology, genetics, immunology, etc. It also can be used in scientific research, universities, medical treatment, epidemic prevention, etc.
FLUORESCENCE MICROSCOPE – KFL 30LED
Adopt an infinity optical system and modular function design.
• Equipped with infinity plan achromatic fluorescent objectives, enable obtain clearer and brighter images.
• Wide-field plan eyepieces: field number Ф22mm.
• Coaxial coarse/fine focus system, with tension adjustable and limit stopper, minimum division of fine focusing: 2μm
• Transmitted illumination: 3W high brightness white LED, brightness adjustable.
• Epi-illumination: 3W high brightness monochromatic LED, enable changing for different wavelength LED, but the brightness can’t be adjustable.
• Trinocular can be used in observing from eyepieces and micro photography in 100% light flux, suits for low illuminance micro photography
|Dimensions||65 × 45 × 40 cm|
Stable & Sturdy, corrosion resistant. Anti-fungal mould treated, single mold modular stand
300 Inclined Siedentopf Binocular/Trinocular tubes, 3600 rotatable with IPD 53-75 mm and dioptric adjustment
WF 10x/22mm with Eye-guards. Anti-fungal mould treated
Quadruple Reverse angle nosepiece
FL Series Fluorescent Plan Objectives, anti-fungal mould treated
4x/NA0.10, 10x/NA0.25, 40x/NA 0.65 (spring loaded), 100x/NA1.25 (spring loaded & oil)
Double layer mechanical stage 210mm x 140mm, range of motion 75mm x 50mm. Integrated mechanical stage with vernier, low-position coaxial control knobs
Adjustable tension control to prohibit drift and adjustable up-stop to protect slides, slide glass and objective lens; Coaxial coarse and fine adjustments with dial marking at 2μm increments
N.A. 1.25 Abbe condenser with Iris diaphragm, rack and pinion focusing
Illumination / Reflected Fluorescence System
3W high brightness white LED, brightness adjustable
3W blue Led (460/470nm), with blue fluorescent filter system. Brightness not adjustable
Input 110-240V 50/60Hz
Packed in molded Styrofoam box with: Operation Manual, Cleaning Cloth and Dust Cover
Orange color plastic screen for protection against UV light, Power code, Spare fuses, Immersion Oil
